Kenwood DMX-120BT
-
Key Features
Clear resistive 6.8" WVGA touch screen Android USB mirorring ready 7 band equalizer 3 preouts, (2.0V) (Front/Rear/Sub(mono)) AV-in, Video-out & RCAM-in Bluetooth handsfree & audiostreaming built-in Rear USB, 1A Charge MP3, WMA, AAC, WAV & FLAC audio file playback MPEG1/2 & MPEG4, H.264, WMV & MKV video file playback Shortbody, only 75mm installation depth
General Features
DIN Size 2 DIN Smooth GUI Yes Key Illumination Blue LED Touch sensor Yes Touch Sensor Tone Yes Optional IR remote controller Yes, KNA-RCDV331 Digital Clock (24H) Yes ISO connector Yes Built-in Bluetooth Yes Android USB Mirroring Yes
Monitor Features
Screen Type Clear resistive touch panel High Resolution VGA Display Yes LCD type 6,8 inch Wide VGA LCD backlight LED Display Mode 1 Mode: Full Touch Panel Clear resistive Display Type Glare NTSC/PAL judge Yes (Auto)
Multimedia GUI Features
OSDC Type Graphic Opening Screen Type standard R-CAM interrupt Yes Menu text in selectable language English(Default), Espagñol, Français, Deutch, Italiano, Nederlands, Finnish, Russian, Português, Polski, Cestina, Magyar.
Tuner Features
Station Select Auto / Manual FM Reception Yes AM Reception Yes, (MW Reception) Tuner Presets (FM/AM) 30 Presets (18FM / 12AM) Up/Down Seek/Scan Yes Automatic Memory Entry (AME) Yes Radio Data System Yes Traffic Information Yes Local search Yes Auto TP search Yes Enhanced Other Networks Function (EON) Yes Program Type Function (PTY) Yes
Bluetooth General Features
Hands Free Profile (HPF) V1.6 Audio Streaming (A2DP) Yes, (SBC) Phonebook Access Profile (PBAP) Yes Voice Control Yes High-quality noise canceling microphone included
CE_Playable Audio file
CE_Playable Video file
MPEG1/2 files are playable USB MPEG4 files are playable USB WMV files are playable USB H.264 files are playable USB mkv files are playable USB JPEG files are playable USB
USB Features
Rear USB Terminal Yes USB Type 2.0 Full speed MP3 playback with ID3 Tag Display Yes WMA (Windows Media File) playback Yes AAC (Advanced Audio Codec) playback Yes MPEG1 Video decoder Yes MPEG2 Video Decoder Yes MPEG4 Video Decoder Yes Repeat/Scan/Random search Yes Repeat / Random Play Yes 1A Charge Capability for Smartphone. Yes
Audio features
Max. Output Power (MOSFET Power IC) 4 x 50W Pre-out 3RCA: Front/Rear/Subwoofer Pre-out Output Level 2V Low Pass Filter (LPF) Yes Subwoofer Reference Level Adj. Yes Balance/Fader Control Yes Loudness Control Yes Equalizer Yes, 7-bands Beep On/Off Yes
Video Features
Audio Video Output Yes Audio/Video Input Yes Video-In for Rear-view Camera 1 dedicated video input (RCA)
Connectivity
USB interface OEM Wired Remote Control ready Yes Parking sensor (handbrake) wire Yes 2-way (Tel/Navi) mute wire Yes AV-Input (Non Switchable) (RCA) AV Output Video only (RCA) Reverse sensor wire Yes Rear View Camera Input FM Antenna Input External microphone input
Tuner Specifications
FM range: 87.5Mhz - 108MHz (50Khz step) Yes FM Usable Sensitivity 12.2μV/75ohm (S/N 26dBf) FM Quieting Sensitivity 19.2μV/75ohm (S/N 26dBf) FM Frequency Response 30Hz ~ 14kHz (± 3dB) FM Signal to noise ratio (Mono) 55dB FM Selectivity(DIN) over 70dB (±400kHz) MW range: 531kHz - 1611kHz (9kHz step) Yes
Bluetooth specifications
Technology bluetooth V2.1+EDR Frequency 2.402 - 2.48 GHz Output power +4dBm(max), 0dBm (AVE) power class 2 Maximum range Line of sight approx. 10 meter Handsfree profile (HFP) Yes, V1.6 Advanced audio distribution profile (A2DP) Yes, V1.2 Audio Codec SBC Audio/Video remote control profile (AVRCP) Yes, V1.3 Phonebook access profile (PBAP) Yes, V1.1.1
USB Specifications
USB Version compatibility 2.0 Full Speed File System FAT 16/32 Maximum Supply current 1000mA D/A Converter 24bit MPEG1 Decoder MPEG-1 with MPEG Audio Layer 2 MPEG2 Decoder MPEG-2 with MPEG Audio Layer 2 MPEG4 Decoder yes MP3 Decode Compliant with MPEG-1/2 Audio Layer-3 WMA Decode Compliant with Windows Media Audio AAC Decode "m4a" & "aac" file encoded by AAC-LC format S/N Ratio 99 dB (1kHz) Dynamic Range 99dB
Audio Specifications
Maximum Power 50W x 4 Output Power (DIN45324,+B=14.4v) 21W x 4 Preout Level 2000mV / 10kOhm, Preout Impedance ≤ 600Ohm Speaker Impedance 4Ohm ~ 8Ohm Graphical Equalizer 7-Band G. EQ. Frequency (Hz) 62,5Hz - 16kHz G. EQ. Gain (dB) -7 / ... / +7 Low Pass Filter Frequency (Hz) 80 / 120 / 160 / Off
Video Specifications
Color System of External Video Input NTSC/PAL External Video Input Level (RCA) 1 Vpp / 75 Ohm External Audio Max. Input Level (RCA) 1.8 V / 10 kOhm
Monitor Specifications
Screen size (Diagonal) 6.75 Inches Wide Screen Size (WxH) 151.8 x 79.7mm Display system Transparent TN LCD Panel Drive system TFT Active Matrix System Number of Pixels 1152000pixels (800(H) x 480(V) x RGB) Effective pixels 99.99% Pixel arrangement RGB Striped Back lighting LED (Light Emitting Diode)
General Specifications
Operating voltage 14.4V (10.5 ~ 16V Allowable) Maximum Current Consumption 10A Dimensions (WxHxD) 182 x 112 x 74.5mm Weight 900 gr. Operation Temperature Range -10°C ~ 60°C
Accessories
Release keys 2 pieces Escutcheon Yes Installation Sleeve Yes Handsfree Microphone with 3 m cable
