Main Features:

• Apple Car Play (via USB)
• Android Auto (via USB)
• Bluetooth Hands Free Call (HFP)
• Bluetooth Audio Streaming & Control (A2DP, AVRCP)
• Bluetooth Voice Dialing (voice recognition compatible mobile phone required)
• Bluetooth Phone Book Access Profile (PBAP)
• Auto Pairing for iPhone/Android
• USB 1.5A High Current Charging
• 13-Band Graphic EQ
• Bluetooth(R) Wireless Technology (*Available functions depend on cell phone.)

Monitor

• Screen Size 6.8" W VGA Screen
• Touch Panel Capacitive
• Monitor Touch Control
• Customisable GUI
• Key Illumination Color Blue
• Dimmer
• Multilingual Display

Media Playback

• MP3 Compatible with Tag USB
• WMA Compatible with Tag USB
• WAV Compatible with Tag USB
• AAC Compatible with Tag USB
• FLAC Compatible with Tag USB
• H.264 Compatible USB
• WMV Compatible USB
• MPEG 1/2 Compatible USB
• MPEG 4 Compatible USB
• AVI/MKV Compatible USB

Bluetooth Control

• Built-In Bluetooth (Wired-Mic included)
• Hands Free Call (HFP1.6 Wideband Speech)
• Supported Audio Formats AAC / SBC
• Audio Streaming & Control (A2DP, AVRCP)
• Voice Dialing (voice recognition compatible mobile phone required)
• Phone Book Access Profile (PBAP)
• Alphabetical Search for Phone Book
• Auto Pairing for iPhone/Android  (Android only)

Android Control

• Android Auto (via USB)
• Android Music Playback (via Bluetooth(R))
• Mirroring for Android  (via USB) *Need mirroring App
• iPod/iPhone Control
• CarPlay (via USB)

USB

• USB Port x 1 (High Speed)
• Position Rear
• USB Power Supply (1.5A High Current Charging)

Radio Tuner

• Radio Data System
• Preset Stations 20(FM:15ch, AM:5ch)
• Automatic Presetting (Strong Station Sequential Memory)
• FM - Frequency Range 87.5-108.0MHz
• AM - Frequency Range (MW)531-1,611kHz,(LW)153-279kHz

Audio

• Maximum Power Output (Front & Rear) 50Wx4
• Full Bandwidth Power (Front & Rear) 22W x 4 (Full Bandwidth Power, at less than 1% THD)
• EQ (13-Band Graphic EQ)
• Preset EQ  (7Preset + 3user)
• High-Pass Filter/Low-Pass Filter
• Bass Boost
• Time Alignment

Inputs and Outputs

• AV Input mini jack (AV-IN or Camera switchable)
• Video Out RCA
• Pre-output Level/Impedance 2.0V / 10k ohms
• Rear view camera Input
• Line Output Terminals 2Preouts (Terminal) + Sub WF (Cable)
• Subwoofer Output with Level/Frequency Control

General

• Back Up Memory
• Wireless Remote Control Ready (RM-RK258 required)
• Steering Remote Control Ready
• Learning Direct OEM Remote
• ISO Connector
• Dimensions (W x H x D)
• Installation Size 182 x 112 x 75 (mm)
• Unit weight in individual package 1.9kg
• Weight 1.3kg : inlcuding sleeve and escutcheon
